Description
Specification
- Slotting Machine is being prepared with genuine component with its accurate size : As well as with latest Technology and all the components are being inspected every stage of production by our qualified staff to maintain quality for ever and we want to achieve satisfaction through our quality products.
- Also we look forward to enhance relationships with our customers as well as attract new business relationship
Description
- Heavy Duty Slotting Machine Model 150
- Adjustable Stroke 10 to 150 mm
- Electric Motor 1 HP 3 Phase
- Slotting Machine
Technical Specification
| SPECIFICATION OF MACHINE | MODEL – 150 |
| Adjustable Stroke | 10 To 150 mm |
| Longitudinal Movement | 200 mm |
| Cross Movement | 110 mm |
| Speed Adjustment | 3 Speed |
| Ram Adjustment | 150 mm |
| Electric Motor | 1 H.P. |
Standard Accessories
- Boring Bar.
- Motor Pulley.
- Counter V-Belt
Extra Accessories
- Rotory Table With 36.1 Ration Diameter 250 Mm
- Electric Motor
- Switch
- True Check
- V-Belt
Other Specification
- A – 210 MM
- B – 310 MM
- C – 280 X 335 MM
