Description
Specifications:-
| TECHNICAL SPECIFICATION | ||
| BED : | Bed Length Bed Width Bed Type Gap Length Gap Length in front of face plate |
1800 MM 240 MM 2 V & 2 Flat 100 MM 110 MM |
| CAPACITY: | Height of Centre Swing Over Bed Swing Over Cross slide Swinging Gap Admit Between Centre Movement of Cross Slide Movement of Compound Slide |
150 MM 300 MM 200 MM 400 MM 1000 MM 175 MM 100 MM |
| MAIN SPINDLE: | Spindle Nose Taper Bore in Spindle Sleeve Spindle Bore |
A2 – 4 MT – 3 Ø 40 MM |
| TAIL STOCK : | Quil Dia Taper in Quill Quill Travel |
41.5 MM MT – 3 150 MM |
| SPEED : | No. of Spindle Speed RPM (Low / High) 1400 RPM Motor RPM (Low / High) 750 RPM Motor |
8 45 to 1200 22 to 600 |
| THREADS: | Metric Thread English Thread Module Thread Diametrial Pitch Lead Screw |
20 (0.5 to 7 MM) 36 (4 to 60) TPI 13 (1 to 4) 12 (6 to 24) 25 MM x 4 TPI |
| ELECTRIC MOTOR: | Main Power | 1.5 KW / 2 HP |
| MOTOR DRIVE: | ‘V’ Belt | B – 30 |
| GENERAL: | Weight (Approx.) | 650 Kg |
