CNC Vertical Machining Centre
Model No :-
PSW/WM/6012
Delivery :- EXW
Minimum Order :- 1 Set
Supply Ability :- 5 Set / month
Country of Origin :- Haryana, India
Note :- We provide products customized to your requirements.
Description
| Specifications | VMC-3-600 | VMC-4-900 | VMC-6-1100 | VMC-6-1200 | VMC-6-1400 | VMC-8-1600 |
| Table
Clamping Area(mm) Distance From Spindle Face to Table(mm) |
300 x 600
100-400 |
450 x900
100-600 |
600 x1100
100-600 |
600 x 1200
100-700 |
600 x 1400
100-700 |
800×1600
100-810 |
| Traverse
X – Axis (mm) Y – Axis (mm) Z – Axis (mm) |
400 300 200 |
600 450 500 |
825 500 500 |
1050 600 600 |
1250 600 600 |
1610 850 710/800 |
| Axis
Rapid (M. Min) Cutting Feed Rate (M/min) |
24/24/20 10000 |
24/24/20 10000 |
24/24/20 10000 |
24/24/20 10000 |
24/24/20 10000 |
24/24/20 10000 |
| Spindle
Max. Speed (RPM) Spindle Taper Spindle Power (kW) |
6000 BT – 40 3.7/5.5 |
6000 BT-40 7.5/11 |
6000 BT-40 7.5/11 |
6000 BT-40 11/15 |
6000 BT-40 11/15 |
6000 BT-40 11/15 |
| Auto Tool Changer (ATC)
No. of Tools |
12/16* |
20/24* |
20/24* |
20/24* |
20/24* |
20/24* |
| Accuracy
Position Accuracy Repeatability |
± 0.010mm ± 0.003mm |
± 0.010mm ± 0.003mm |
± 0.010mm ± 0.003mm |
± 0.010mm ± 0.003mm |
± 0.010mm ± 0.003mm |
± 0.010mm ± 0.003mm |
*Specifications may be modified without prior notice, in accordance with ongoing improvements or updates.
